Comm./Data Drop In Floor Box- Brass Cover
One Gang, Drop In Floor Box With Brass Dual Flip Lid Cover And RRP-2-PQ Device for Comm./Data
Part Number: SWB-2-LR-T
Application Selector: Residential
Type: Floor Box
Product Family: POWERDEN, SWB Series Boxes and Replacement Covers, SWB-2 Box Assemblies and Replacement Covers
Floor Box Type: Rectangular Drop In
Finish Floor Type: Carpet, Tile, Wood
Floor Box Cover Type: Dual Flip Lid
Cover Shape: Rectangular
Finish Color: Brass
Box Material: Stamped Steel
Box Capacity: 1G
Service Capacity: Single
Plug Connection Type: Surface
Receptacle Included: Quad Port Low Volt
Description
Recessed Floor Plate with Box, One RRP-2-PQ, 2 Flip Lids, Brass
The Lew Electric SWB-2-LR-T is a recessed floor plate with brass flip lid cover, single gang stamped steel box and adjusting sleeve. Inside the floor box is a Lew RRP-2-PQ quad port Comm./Data receptacle. The adjusting sleeve is adjustable up to 3/4″ to accommodate any floor. The box features two water tight flip lids and a durable 1/16″ neoprene rubber gasket that goes between the receptacle and plate. The stamped steel box is UL listed.
Specifications
- Plate: 1/4″ Brass
- Outlet: RRP-2-PQ quad port for Comm./Data connectors
- 2 watertight flip lids
- Adjustable up to 3/4″
- Includes 1/16″ neoprene rubber gasket
- Cover size: 4 5/8″ x 2 7/8″
- Back box size: 3″L x 2″W x 3.5″H
- Cutout size: Can’t exceed 2 1/8″ x 3 1/2″
- Capacity: 18 cubic inches
- Warranty: 1 year
UL & NEMA RECOGNITION
- Box UL #E345966
- Meets NEMA WD1-1983 heavy duty requirement for display receptacle
FEATURES & BENEFITS
- Versatile power or communications applications
- Water tight assembly
- 1/2″ Conduit knockouts
- Adjustable up to 3/4″ to accommodate any floor
